Unbound

Unbound is a recursive DNS resolver installed on NCC-1702, NCC-1703, and NCC-1704 to handle upstream DNS resolution for Pi-hole.

Why Unbound instead of a forwarding resolver?

Most DNS setups forward queries to a public resolver (Cloudflare 1.1.1.1, Google 8.8.8.8, etc.). This works, but it means that resolver can see every domain you query.

Unbound removes that dependency. Instead of handing queries off to a third party, it resolves them recursively — starting at the DNS root and working down the hierarchy itself:

1. "Who handles .com?" → asks a root nameserver
2. "Who handles example.com?" → asks the .com TLD nameserver
3. "What is www.example.com?" → asks Example's authoritative nameserver

No single upstream provider sees your full query traffic. Pi-hole still handles ad and tracker blocking; Unbound handles the resolution.

Root hints file

To start the recursive resolution process, Unbound needs to know the IP addresses of the DNS root nameservers. These are provided via a root hints file (root.hints), published by IANA.

Without it, Unbound falls back to a compiled-in list that can go stale as root server addresses change over time. Keeping a current root hints file ensures Unbound always knows the right starting points.

To update the root hints file on a bare-metal install:

wget -O /var/lib/unbound/root.hints https://www.internic.net/domain/named.root
sudo systemctl restart unbound

This should be done periodically (a few times a year is sufficient — the root hints change rarely but do change).

For a Docker install, the root hints file is baked into the image at build time. To keep it persistent and independently updatable, it is bind-mounted from the host:

volumes:
  - /ssd/docker/appdata/pihole/unbound/root.hints:/opt/unbound/etc/unbound/root.hints:ro

Note the path inside the container — mvance/unbound builds Unbound from source into /opt/unbound/ rather than using the system paths of a bare-metal install.

To update the hints on the Docker install:

wget -O /ssd/docker/appdata/pihole/unbound/root.hints https://www.internic.net/domain/named.root
docker restart unbound

Bare-metal configuration (NCC-1702 & NCC-1703)

On the Raspberry Pi devices, Unbound is installed directly via apt and listens on port 5335 to avoid conflicting with any system resolver on port 53.

sudo apt install unbound

Config at /etc/unbound/unbound.conf.d/pi-hole.conf:

server:
    verbosity: 0
    interface: 127.0.0.1
    port: 5335
    do-ip4: yes
    do-udp: yes
    do-tcp: yes
    do-ip6: no

    root-hints: /var/lib/unbound/root.hints

    harden-glue: yes
    harden-dnssec-stripped: yes
    use-caps-for-id: yes

    edns-buffer-size: 1472
    prefetch: yes
    num-threads: 1

    private-address: 192.168.0.0/16
    private-address: 169.254.0.0/16
    private-address: 172.16.0.0/12
    private-address: 10.0.0.0/8

Pi-hole (v6) on these devices is then configured to use 127.0.0.1#5335 as its upstream DNS server. This is set either via the web UI under Settings → DNS → Custom upstream, or directly in /etc/pihole/pihole.toml:

[dns]
  upstreams = [ "127.0.0.1#5335" ]

Docker configuration (NCC-1704)

On NCC-1704, Unbound runs as a sidecar container (mvance/unbound) on the same Docker network as Pi-hole, with a static IP of 172.20.0.4. Pi-hole is configured to send upstream queries to unbound#53 (resolved internally by Docker to 172.20.0.4).

See the NCC-1704 page for the full compose configuration.
